VIPER22A IC -SMPS Primary Switcher IC ( 5 Pcs Pack)

Original price was: ₹150.00.Current price is: ₹125.00.

Features:-

Fixed 60kHZ Switching Frequency
9V to 38V Wide Range VDD Voltage
Current Mode Control
Auxiliary Under voltage Lockout with Hysteresis
High Voltage Start-up Current Source
Over temperature, Over current and Over voltage Protection with Auto-Restart control Boost PWM to 0.99 Power Factor

Compare

Categories: DIP IC's, All Items, Voltage Regulators Tags: IC, SMPS, viper, viper22a

Description

VIPER22A IC

The VIPer22A combines a dedicated current mode PWM controller with a high voltage Power MOSFET on the same silicon chip. Typical applications cover off line power supplies for battery charger adapters, standby power supplies for TV or monitors, auxiliary supplies for motor control, etc.

The internal control circuit offers the following benefits: – Large input voltage range on the VDD pin accommodates changes in auxiliary supply voltage. This feature is well adapted to battery charger adapter configurations. – Automatic burst mode in low load condition. – Over voltage protection in HICCUP mode.

VIPER22A IC Data Sheet
